HDBaseT Extender Set – 100m (4K up to 70m), Bi-directional IR, RS232, Bi-directional PoC


Video Input Connectors$$1 x HDBaseT RJ45 connector
Video Output Connectors$$1 x HDMI Type A, female
RS-232 Input Port$$ 1 x 3-pin Phoenix connector
IR Input Port$$ 1 x 3.5mm stereo jack
IR Output Port$$ 1 x 3.5mm mono jack
Audio Input/Output Ports$$Optical in, Optical out, Analog L/R out Mounting Kit included
Casing Dimensions (W x H x D)$$140 x 84 x 18mm
Dimensions Including Connections (W x H x D)$$ 140 x 98 x 18mm
Power Supply$$ 24V/1.25A DC, 4-pin connector (not included)
Shipping Weight$$ 0.5Kg
Operating Temperature$$ 23°F to 131°F (-5°C to +55°C)
Storage Temperature$$ -13°F to 158°F (-25°C to +70°C)

Package Contents:

  • 1 x EL-4KHDBT-RX-70-ARC-18G
  • 1 x Mounting Bracket Set
  • 1 x Quick Reference Guide
